Gucbir Jenerator produces the generators in Turkey accordance to European Quality Standards by focusing and targeting the top quality

Genset Brand Gucbir Generator
Genset Model GJR330
Standby Power kVA 330
Prime Power kVA 300
Frequency Hz. 50
Voltage V 230/400
Phase 3
Fuel Diesel
Control Panel Datakom GB500
Country of Origin Turkey
Category:
Description
Standby kVA 400
Prime kVA 360
Engine Brand Ricardo
Engine Model 6D12D320A
Alternator Brand Maranello
Alternator Model M400
REQUEST A QUOTE

    CALCULATE
    Jeneratör güç hesaplama


      GENERATOR POWER CALCULATION - FORMULAS


    You can find the capacity of the generator you need by using the tables below. The purpose of these tables is to help you calculate the power and electricity you need.
    Electrical and Power Standards Table
    Kilo Volt Ampere kVA
    KiloWatt (1000 watts = 1 kW) kW
    Amper (Volt-Ampere) I
    Volt E
    Power Factor PE
    Percent Efficiency %EFF
    Horse Power HP

    Power Requirement Calculation
    Number of Phases Volt requirement
    V    		 Aampere
    I

    Power

     Factor

    		 = Power
     kW
    1
    3
    		 .8
    1.0
    Convert from kW to kVA
    kW = kVA
    kVA to kW conversion
    kVA = kW
    Convert kW to HP
    kW = HP
    Generator power required to start a 3-phase electric motor (DOL-Demurrage)
    Engine Power (HP)
    		= Generator
    kVA need
    Calculate Amps (kVA If Known)
    Phase
    1,2,3    		 Generator
    kVA    		 Voltage
    Requirement    		 = Ampere
     I






    ENGINE
    Engine Brand RICARDO Engine Model 6D10258A Standby Power kWm 283 Prime Power kWm 258 Fuel Type Diesel Number of Cylinders and Type 6 – Vertical In Line Bore and Stroke mm 126×130 Total Displacement L 9,7 Aspiration Turbocharged /Aftercooler Compression Ratio 18:1 Rated Speed Rpm 1500 Injection Type and System Indirect injection Governor System Electronics Operating Voltage Vdc 24 Cooling System Water Cooled Air Filter Type Dry Type
